Caratteristiche
Peso
Altezza
Larghezza
Profondità
Diametro tubo scarico fumi
Diametro tubo aspirazione aria
Volume di riscaldamento max
Potenza termica globale max
Potenza termica utile max
- potenza resa all'aria
- potenza resa all'acqua
Potenza termica globale min
Potenza termica utile min
- potenza resa all'aria
- potenza resa all'acqua
Consumo orario combustibile max
Consumo orario combustibile min
Capacità serbatoio
Tiraggio del camino consigliato
Tiraggio del camino alla potenza termica utile max
Tiraggio del camino alla potenza termica utile min
Potenza elettrica nominale
Potenza elettrica apparecchio
Tensione nominale
Frequenza nominale
Diametro tubo entrata/uscita acqua
Diametro tubo scarico automatico
Prevalenza pompa
Max pressione idrica di esercizio ammessa
CO misurato alla potenza termica utile max
CO misurato alla potenza termica utile min
Rendimento alla potenza termica utile max
Rendimento alla potenza termica utile min
Temperatura gas di scarico alla potenza termica utile max Exhaust gas temperature at max. useful thermal output
Temperatura gas di scarico alla potenza termica utile min Exhaust gas temperature at min. useful thermal output
Massa dei gas emessi alla potenza termica utile max
Massa dei gas emessi alla potenza termica utile min
Emissioni polveri alla potenza termica utile max
Emissioni polveri alla potenza termica utile min
Prove eseguite usando come combustibile pellet di legno con potere calorifi co pari a 4.9 kWh/kg.
Tests done using wood pellet (as fuel) by heating power of 4.9 kWh/kg.
Stufa a pellet modello / pellet stove model : Comfort Mini
Informazioni marcatura / Marking information
COMFORT MINI
08
EN 14785 : 2006
Features
Weight
Height
Width
Depth
Outlet fumes pipe diameter
Air intake pipe diameter
Max. heating volume
Max. overall thermal output
Max. useful thermal output
- power given back to air
- power given back to water
Min. overall therman output
Min. useful thermal output
- power given back to air
- power given back to water
Max. hourly fuel consumption
Min. hourly fuel consumption
Tank capacity
Recommended fl ue pipe draft
Flue pipe draft at max. useful thermal output
Flue pipe draft at min. useful thermal output
Rated electric output
Appliance electric output
Rated voltage
Rated frequency
Water intake/outlet pipe diameter
Automatic discharge pipe diameter
Pump head
Max. admitted operating water pressure
CO measured at max. useful thermal output
CO measured at min. useful thermal output
Performance at max. useful thermal output
Performance at min. useful thermal output
Gas mass given off at max. useful thermal output
Gas mass given off at min. useful thermal output
Dust emissions off at min. useful thermal output
Dust emissions off at min. useful thermal output
Valore
U.M.
Value
kg
122
mm
550
mm
700
mm
445
mm
80
mm
50
m3
156
kW
7.8
kW
6.8
kW
6.8
kW
-
kW
3.8
kW
3.5
kW
3.5
kW
-
kg/h
1.6
kg/h
0.7
kg
~ 12
Pa
~ 10
Pa
12
Pa
10
W
300
W
300
Vac
230
Hz
50
"
-
"
-
m
-
bar
-
%
0.019
%
0.023
%
86.4
%
92.9
°C
184.1
°C
108.3
g/s
6.6
g/s
2.9
mg/m3
23.0
mg/m3
36.0
