Table of Contents
Table des matières • Sommario • Inhaltsverzeichnis •
Contenidos • 目次 • 目录
English
Français
Italiano
Deutsch
Español
日本語
中文
3
6
9
12
15
18
21
2
x2 Fender & Fender Frame
Tools required
4mm hex wrench
Included with Fender:
20961-00001 Left • 20962-00001 Right
Included with Fender Frame:
20959-00001 Left • 20960-00001 Right
Installation instructions for all Segway
1. Make sure the Segway PT is unplugged and powered off.
2. To remove the Fender & Frame Assembly from the PT, remove the (3) 28mm
fasteners using a 4mm hex wrench. See Figure 1.
3. Lift off the Fender & Frame Assembly and clean all debris from the mounting
surfaces.
WARNING!
Before performing any maintenance or installing any part or accessory:
Shutdown Unplug
Follow all instructions carefully to avoid
the Segway PT. the Segway PT.
serious injury, death and/or damage to the
Segway PT, rendering it unsafe to use.
The Fender, Frame and Fender Frame Assembly must be properly installed
and secured. Failure to properly install the Fender, Frame and Fender Frame
Assembly or to adhere to torque specifi cations when tightening fasteners could
result in machine malfunction and could cause personal injury or damage to
your Segway PT.
(1) x2 Fender
(4) Fasteners, 18mm long
(1) x2 Fender Frame
(4) Fasteners, 18mm long
(3) Fasteners, 28mm long
x2 models
®
3
