7.

Accessories

Fitting and functional accessories are available via www.sed-flowcontrol.com or contact us.
8.

Troubleshooting

Fault
Valve leaks downstream
(doesn't close or doesn't
close fully)
Valve doesn't open or
doesn't open fully
Medium escapes from the
valve spindle* (underneath
handwheel)
Valve leaks between
bonnet and valve body
Valve body connection to
piping leaks
Valve body leaks
© 2019 SED Flow Control GmbH, Bad Rappenau
Potential cause
Operating pressure too high
Foreign matter between seat
seal* and seat
Valve body leaky or damaged
Seat seal faulty
Bonnet faulty
metal bellows faulty
Bonnet loose
flat sealing faulty
Valve body / bonnet damaged
Incorrect installation
Threaded connections / flange
bolting loose
Sealing components faulty
Valve body leaks or is corroded
33
Solution
Operate valve with operating
pressure specified
in data sheet
Remove bonnet, remove
foreign matter, check
seat seal for damage and
replace if necessary
Check valve body and replace
if necessary
Check seat seal for damage
and replace if
necessary
Replace bonnet
Replace bonnet
Retighten bonnet retaining nut
Check gasket and the
respective sealing surfaces
for damage and replace parts if
necessary
Replace valve body / bonnet
Check installation of valve body
in piping
Retighten threaded
connections / flange bolting
Replace sealing components
Check valve body for damage,
replace valve body
if necessary
