Intermediate & Large Frame Snowthrowers
17
AUGER GEAR CASE LUBRICATION
1. Place the snowthrower on a level surface.
2. Remove the pipe plug (A, Figure 22).
3. Check the lubricant level. It should be level with the
lower edge of the plug opening. If not, add Simplicity
Winter Weight Worm Gear Oil (available from your
dealer).
4. Re-install pipe plug, and tighten securely.
TP 399-4222-01-LW-SN
Figure 22. Auger Lubrication
A. Pipe Plug
24
A
8/2005
