Device Configuration - HP 9250C Digital Sender Kurzanleitung

Manually assign an IP address
1. Touch Administration, and then touch Initial Setup.
2. Touch Networking and I/O, and then touch Embedded Jetdirect.
3. Touch TCP/IP, and then touch either IPV4 Settings (such as http://192.168.1.1) or IPV6 (such as
http://[2001:0ba0:0000.0000.0000.0000.0000:1234]).
4. Touch Config Method.
5. Touch Manual, and then touch Save.
6. Touch Manual settings.
7. Touch IP address. Touch the IP address field, and then type the IP address.
8. Touch OK.

Device configuration

Before configuring, have the following information:
●
The host name or IP address of the simple mail transfer protocol (SMTP) e-mail server that will
send e-mail from the digital sender
●
The host name or IP address of the Lightweight Directory Access Protocol (LDAP) server that will
retrieve e-mail addresses (optional)
● The preferred folder paths for the send-to-folder feature
●
The host name or IP address of the digital sender
Use the following keys on the keyboard to help navigate through the configuration screens.
●
Press the Escape key to return to the previous screen.
● Press the Tab key to move the cursor to the next field.
6 Install and Setup the Device ENWW
