Q. UNBALANCED LINE OUT—Provides unbalanced preamp
output for an auxiliary amplifier or sound equipment that
includes the effects loop signal. Output level is controlled
by MASTER Volume {C}. DIRECT/LINE and PAD {S} also
affect this output.
R. TUNER OUT—Plug in your bass guitar tuner here to
enable inline tuning. Use MUTE {B} to disable audio out-
put while tuning.
S. BALANCED (XLR) OUTPUT—A true electronically bal-
anced output, suitable for studio and "front-of-house"
(live) mixing consoles. The function of each of the three
BALANCED OUTPUT switches are described below. Wiring
for this jack is the "American Standard."
DIRECT / LINE—Connects the BALANCED OUTPUT
and UNBALANCED LINE OUT jacks to the signal path
PART NUMBERS:
POWER REQUIREMENT:
POWER AMP
MINIMUM IMPEDANCE: 4Ω
PRE AMP
SENSITIVITY AT FULL POWER: 75mV
TONE CONTROLS
EFFECTS LOOP
UNBALANCED LINE OUT
BALANCED LINE OUT
SPEAKER:
FOOTSWITCH (OPTIONAL):
LINE FUSE
DIMENSIONS
WEIGHT:
Rear Panel

Specifications

4452400010 (120V, 60Hz)
4452404010 (230V, 50Hz) UK
4452407010 (100V, 50Hz) JPN
330W
POWER OUTPUT: 100W RMS into 4Ω @ < 0.1% THD, 1kHz
INPUT IMPEDANCE: 3.9MΩ
BASS: ±15dB @ 100Hz
TREBLE: ±15dB @ 5kHz
MID: ±15dB @ 1kHz
SEND IMPEDANCE: 2kΩ
RETURN IMPEDANCE: 27kΩ
SEND IMPEDANCE: 1kΩ
SEND IMPEDANCE: 1.5kΩ
Eminence® 4Ω, 10'' (P/N 071299)
2-button, Mute, Bass Intensifier (P/N 065436)
110V-120V MODELS: F4A L, 250V
230V-240V MODELS: F2A L, 250V
HEIGHT: 18.2 in (47 cm)
WIDTH: 17.9 in (45 cm)
DEPTH: 15.3 in (39 cm)
41 lb (18.6 kg)
Product specifications are subject to change without notice.
◊
before (DIRECT) or after (LINE) the onboard tone shap-
ing and MASTER volume circuits.
GROUND / LIFT—Disconnects the BALANCED
OUTPUT ground connection (LIFT) which may reduce
hum noise due to a ground loop (non-standard XLR
wiring). Normally leave this switch out (GROUND).
NOTE: Lifting the ground connection will not solve
hum noise due to bad cables, poor connections,
miswired A/C outlets, nearby fluorescent lighting
(especially with single-coil pickups) or a cell phone in
your pocket.
0dB / –10dB—Reduces the BALANCED OUTPUT
and UNBALANCED LINE OUT levels by –10dB. Normally
leave this switch out (0dB).
4452403010 (240V, 50Hz) AUS
4452406010 (230V, 50Hz) EUR
◊ 9
