Vooringestelde fabrieksinstellingen

Model UVM-2600

Modus
VGA 640 x 480 @ 60 Hz
VGA 640 x 480 @ 72 Hz
VGA 640 x 480 @ 75 Hz
SVGA 800 x 600 @ 56 Hz
800 x 600 @ 60 Hz
SVGA
800 x 600 @ 72 Hz
SVGA
800 x 600 @ 75 Hz
SVGA
XGA 1024 x 768 @ 60 Hz
XGA 1024 x 768 @ 70 Hz
XGA 1024 x 768 @ 75 Hz
SXGA 1152 x 864 @ 75 Hz
SXGA 1280 x 960 @ 60 Hz
SXGA 1280 x 1024 @ 60 Hz
SXGA 1280 x 1024 @ 75 Hz
HD 1366 x 768 @ 60 Hz
Modus
EGA 640 x 350 @ 70 Hz
DOS 720 x 400 @ 70 Hz
Modus
VGA 640 x 480 @ 67 Hz
SVGA 832 x 624 @ 75 Hz
SVGA 152 x 870 @ 75 Hz
Modus
SVGA 1280 x 1024 @ 70 Hz
De LCD monitor beschikt alleen over non-interlaced modi zonder flikkering.

Modellen UVM-3200 / UVM-4200

Modus
VGA 640 x 480 @ 60 Hz
VGA 640 x 480 @ 72 Hz
VGA 640 x 480 @ 75 Hz
SVGA 800 x 600 @ 56 Hz
SVGA 800 x 600 @ 60 Hz
SVGA 800 x 600 @ 72 Hz
Gebruikershandleiding
Resolutie H-freq. (kHz)
Resolutie H-freq. (kHz)
Resolutie H-freq. (kHz)
Resolutie H-freq. (kHz)
Resolutie H-freq. (kHz)
VESA-modi
V-freq. (Hz)
31,5
37,9
37,5
35,2
37,9
48,1
46,9
48,4
56,5
60,0
67,5
60,0
64,0
80,0
47,7
IBM-modi
V-freq. (Hz)
31,5
31,3
MAC-modi
V-freq. (Hz)
35,0
49,7
68,7
MAC-modi
V-freq. (Hz)
74,4
VESA-modi
V-freq. (Hz)
31,5
37,9
37,5
35,2
37,9
48,1
Opmerking
60 Non-interlaced
72 Non-interlaced
75 Non-interlaced
56 Non-interlaced
60 Non-interlaced
72 Non-interlaced
75 Non-interlaced
60 Non-interlaced
70 Non-interlaced
75 Non-interlaced
75 Non-interlaced
60 Non-interlaced
60 Non-interlaced
75 Non-interlaced
60 Non-interlaced
Opmerking
70 Non-interlaced
70 Non-interlaced
Opmerking
67 Non-interlaced
75 Non-interlaced
75 Non-interlaced
Opmerking
70 Non-interlaced
Opmerking
60 Non-interlaced
72 Non-interlaced
75 Non-interlaced
56 Non-interlaced
60 Non-interlaced
72 Non-interlaced
