R10 EXIT
Turns the OSD window off and moves from
sub Menu to top menu in the OSD window.
R11 / R17 UP/DOWN
Press UP/DOWN button to enter the Function
menu.
R12 / R14 LEFT/RIGHT
Press LEFT/RIGHT Button to adjust the
volume.
R13 OK
Select menu items. R15 VOL +/-
Adjust the sound level.
R16 PR +/-
Not used.
R18 PC
Directly select PC mode.
R19 S.MODE
Choose a different preset sound mode or your
own customized sound.
R20 AUTO
Choose automatically the correct horizontal
Position and vertical position as well as the
size of the screen image. (PC mode only)
R21
Not used.
R22 POSITION
Select the position of PIP display.
R23 ZOOM
Select the screen format (CAM/HDMI mode
only).
R24 SIZE
Select the size of PIP display.
R25 SKIP
Not used.
R26 PIP
Activate or cancel the PIP function.
R27 S. SWAP
Change the sound source of the main or sub
display.
R28 SOURCE
Select the signal source of the sub display.
R29 P. SWAP
Change the picture of the main or sub display.
R30, R31, R32, R33
Not used.
Inserting batteries into the remote control unit
Open the battery compartment of the remote
control. Insert the batteries (two 1.5 V type R03 or
EN 4
 
/ Button
 
/ Button
AAA). Make sure that the polarity matches with the
(+) and (-) marks inside of the battery compartment.
Note: To avoid damage from possible battery
leakage, remove the batteries if you do not plan to
use the remote control handset for an extended
period of time.
Changing a monitor
parameter
1. Press the MENU button on the front panel to
obtain the OSD menu screen.
2. Use Left-Right buttons to select the menu.
3. Use Down button to select the submenus.
4. Use Up-Down buttons to select a submenu
function.
5. Press SOURCE button, then using left-right
buttons you can make adjustments as
necessary
6. To exit press, MENU.

Hot keys

Selects signal in order. VGA
- HDMI - CAM
When there is no OSD, if

you press this ▲ (UP/AUTO)
button, you can use the best
display performance fit for a
current mode
When there is no OSD, you
 
can adjust the volume
directly
