Appendix A
A.3 Communication Port Connector
PIN Assignment
1 Carry detect
2 Received data
3 Transmit data
A.4 USB Port Connector
PIN Assignment
1 +5VS
3 USBP0+
A.5 VGA Monitor Connector
PIN Assignment
1 RED
2 GREEN
3 BLUE
4 N.C.
5 GROUND
Page A-2
PIN
4
5
6
PIN
2
4
PIN
6
7
8
9
10
Information in this document is subject to change without notice!!!
Model 400M & 700T User's Manual
Assignment
Data Terminal
GROUND
Data Send
Assignment
USBP0-
GND
Assignment
GROUND
GROUND
GROUND
N.C.
GROUND
PIN Assignment
7 Req. to send
8 Clear to send
9 Ring indicator
PIN Assignment
11 N.C.
12 N.C.
13 HSYNC
14 VSYNC
15 N.C.
