Model 400M & 700T User's Manual
Appendix A - Connectors and Pin
A.1 Keyboard or PS/2 Mouse Connector
A.2 Printer Port Connector
PIN Assignment
1 STROBE #
2 DATA 0
3 DATA 1
4 DATA 2
5 DATA 3
6 DATA 4
7 DATA 5
8 DATA 6
9 DATA 7
Assignments
PIN Assignment
1 Keyboard data
2 No Connection
3 Ground
PIN
10
11
12
13
14
15
16
17
18
Information in this document is subject to change without notice!!!
PIN
4
5
6
Assignment
Acknowledge
BUSY
Paper Empty
Selected
Auto Feed #
ERROR #
INITIALIZE
SLIN #
GROUND
Appendix A
Assignment
+5V
Keyboard clock
No connection
PIN Assignment
19 GROUND
20 GROUND
21 GROUND
22 GROUND
23 GROUND
24 GROUND
25 GROUND
Page A-1
