Appendix A
A.8 S-Video Connector
PIN Assignment
1 GND
2 GND
A.9 IEEE 1394 Connector
PIN Assignment
1 TPB0
2 TPB0#
Page A-4
PIN
3
4
PIN
3
4
Information in this document is subject to change without notice!!!
Model 400M & 700T User's Manual
Assignment
Y
C
Assignment
TPA0
TPA0#
