11
Control states: 0=Heat, 1=Heat/Heat,
2=Heat or cooling via Change-over,
3=Heat/Cooling , 4=Heat/Cooling with VAV-
control and forced supply air, 5=Heat/Coo-
ling with VAV-control, 6=Cooling , 7=Coo-
ling/Cooling
12
Time in Bypass mode
13
Disconnect timer with occupancy/unoc-
cupancy
14
Switch on delay for occupancy
15
State connected sensor on AI1:
0=Internal sensor, 1=External room sensor
16
State connected sensor on UI1:
0=None, 1=Change-over digital, 2=Change-
over analogue
18
State connected sensor on DI2:
1=Window contact, 2=Condensation detec-
tor
20
State function of signal on UO1:
0=None, 1=Thermal actuator heat, 2=None,
3=Heating actuator 0...10V, 4=None
21
State function of signal on UO2:
0=None, 1=None, 2=Thermal actuator coo-
ling, 3=None, 4=Cooling actuator 0...10V
29
State output signal range for heating actuator:
0=0...10V, 1=2...10V, 2=10...2V, 3=10...0V
30
State output signal range for cooling actuator:
0=0...10V, 1=2...10V, 2=10...2V, 3=10...0V
31
Period time for heating actuator with thermal
actuator
32
Period time for cooling actuator with thermal
actuator
33-35
No function for this model
36
Time in hours between exercise of heating
actuator
37
Time in hours between exercise of cooling
actuator
42
Select if setpoint or actual value is to be
shown on display, 0=Actual, 1=Heating set-
point, 2=Cooling setpoint, 3=Average value
of heating and cooling setpoint, 4=Only
setpoint adjustment
43
Highest permitted setpoint offset upwards
44
Highest permitted setpoint offset downwards
3
45
Preset operating mode:
1=Unoccupied, 2=Stand-by,
3=Occupied. Forced ventilation is not set in
Occupied mode
46
State operating mode by depressing Oc-
cupancy button for 5 sec:
120 min
0=Off, 1=Unoccupied. Forced ventilation is
not set in Occupied mode.
10 min
47
No function for this model
0 min
48
Min. flow at cooling output with regulating
state heat/cool when VAV-control is selected
0
49
Max. flow at cooling output with regulating
state heat/cool when VAV-control is selected
2
and heating is applied
50-55
No function for this model
2
56
Temperature compensation on AI1
57
Temperature compensation on UI1
58
Temperature compensation for internal
3
room sensor
59
Filter factor for analogue temperature inputs 0,2
60
State NO/NC digital input 1: 0=NO
4
(Normally open), 1=NC (Normally closed)
61
State NO/NC digital input 2: 0=NO
(Normally open), 1=NC (Normally closed)
0
62
State NO/NC universal input 1: 0=NO
(Normally open), 1=NC (Normally closed)
0
63
Manual/Auto heating output signal: 0=Off,
1=Manual, 2=Auto
60 s
64
Manual/Auto cooling output signal: 0=Off,
1=Manual, 2=Auto
60 s
65
Manual/Auto forced ventilation: 0=Off,
1=On, 2=Auto.
66
Manual/Auto control of change-over mode:
23
0=Heating control, 1=Cooling control,
2=Automatic change-over depending on
23
analogue temperature sensor or digital
input
0
67
Heating output signal in manual mode
68
Cooling output signal in manual mode
69-72
No function for this model
73
Selection of heating output function (NO/
NC): 0=NC, 1=NO
3°C
3°C
3
1
20
0
0°C
0°C
0°C
0
1
0
2
2
2
2
0
0
0
RC-DO
74
Setpoint display at setpoint adjustment:
0=The offset is shown in the display, 1=The
active setpoint + offset are shown in the
display. HEAT or COOL is shown depen-
ding on whether the unit controls according
to the heating or cooling setpoint when you
enter the menu, 2=The heating setpoint
+ offset are shown in the display, 3=The
cooling setpoint + offset are shown in the
display
This product carries the CE mark.
For more information, see www.regincontrols.com.
