ON THE 8445190 MOBILE BASE
Pinch the pincers "K" (Fig. 6) and insert the sandpaper
as indicated. It is important to ensure that the orifices
of the sandpaper coincide with those of the machine
base and that the sandpaper is perfectly taut on the
base. To perforate or centre abrasives, use accessory
8445232, ABRASIVE CENTRING-PERFORATING DEVICE.
ON THE 8445198 DELTA VELCRO MOBILE BASE
Velcro abrasives must be used with this type of base. To
insert sandpaper in the machine, proceed as indicated
in (Fig. 7).
ON THE 8445200 ROTARYORBITAL BASE PLATE
Place the abrasive disk on the plate (Fig. 8) matching
the holes in the disk with those in the plate.
If the sandpaper does not have holes, they can be copied
from the holes in the plate.
9. CONNECTION TO AN EXTERNAL
SUCTION SOURCE
To connect the machine to the AS182K, AS282K aspirators
or to any other external suctioning source, install the
dust collection attachment (ref. 6446073 of 3.5 m or
1746245 of 5 m length) (optional accessory). To do so,
remove the suction bag "L" (Fig. 9) and fit nozzle "M" of
the dust collection attachment in its place.
The other end of the dust collection attachment is
connected to the external suctioning source of choice.
10. CHANGING BRUSHES
Brushes should be changed after 1000 hours of operation
by VIRUTEX technical service.
11. LUBRICATION AND CLEANING
The machine is shipped from factory completely lubri-
cated and does not require special care over the course
of its useful life. It is important to clean the machine
carefully after each use with a blast of dry air.
Keep the feed cable in perfect condition.
Keep all of the machine's ventilation and cooling ope-
nings clean and free from obstruction.
12. NOISE LEVEL AND VIBRATIONS
The noise and vibration levels of this device have been
measured in accordance with European standard EN
60745-2-4 and EN 60745-1 and serve as a basis for com-
parison with other machines with similar applications.
The indicated vibration level has been determined for
the device's main applications and may be used as an
initial value for evaluating the risk presented by expo-
sure to vibrations. However, vibrations may reach levels
that are quite different from the declared value under
other application conditions, with other tools or with
insufficient maintenance of the electrical device or its
accessories, reaching a much higher value as a result
of the work cycle or the manner in which the electrical
device is used.
Therefore, it is necessary to establish safety measures
to protect the user from the effects of vibrations, such
as maintaining both the device and its tools in perfect
condition and organising the duration of work cycles
(such as operating times when the machine is subjected
to loads, and operating times when working with no-load,
in effect, not in use, as reducing the latter may have a
considerable effect upon the overall exposure value).
13. WARRANTY
All VIRUTEX power tools are guaranteed for 12 months
from the date of purchase, excluding any damage which
is a result of incorrect use or of natural wear and tear
on the machine. All repairs should be carried out by the
official VIRUTEX technical assistance service.
14. RECYCLING ELECTRICAL EQUIPMENT
Never dispose of electrical equipment with domestic was-
te. Recycle equipment, accessories and packaging in ways
that minimise any adverse effect on the environment.
Comply with the current regulations in your country.
Applicable in the European Union and in European
countries with selective waste collection systems:
If this symbol appears on the product or in the accom-
panying information, at the end of the product's useful
life it must not be disposed of with other domestic waste.
In accordance with European Directive 2002/96/EC, users
may contact the establishment where they purchased the
product or the relevant local authority to find out where
and how they can take the product for environmentally
friendly and safe recycling.
VIRUTEX reserves the right to modify its products wi-
thout prior notice.
