3.5 Dimensions

31.4
Fig. 6 VGB-103 compact dosing unit
10
ca. 257
131.7
82.4
With closed yoke
With
connection G 1
or G 3/4
71.1
101
ca. 197
187.8
81.8
0
bar 16
With pressure gauge G 1
31.4
146
63
VGB-103
40.3
14
