Operating Instructions
Figure 12: Plug connection for 4 mm pneumatic hose (push-in fitting, PIF)

6 Electrical connection

The electrical connection is established using a round connector M12 x 1. Table 3, Figure 13, Table 4, and
Figure 14 display the pin assignments for the various device versions/existing output signals.
CAUTION
Please observe the information regarding the electrical properties of the pressure switch in
Section 9 (Technical data).
8017612/YJ70/2015-02-24 | PAC50
Subject to change without notice
6 Electrical connection
O p e r a t i n g I n s t r u c t i o n s | S I C K
PAC50
5 7
