CHIEF iCSPAC1 Installationsanleitung Seite 6

iCSPAC1
2
2
6
Install Display
WARNING:
FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE
TO EQUIPMENT. NEVER substitute hardware! Use only hardware
provided by manufacturer when installing a display.
1. Install display following the instructions provided with the mount.
NOTE:
Most displays will be mounted using the four M6x12mm Phillips
pan head machines screws (E) (provided). However, the
mounting holes in some displays require the four M4x12mm
Phillips pan head screws (B) (provided) and two M4 flat washers
(D) (provided). When M4 hardware is required, install two
M4x12mm Phillips pan head screws (B) into the top two
mounting holes in display and hang display on bracket. Then
install two M4x12mm Phillips pan head screws (B) and two M4
flat washers (D) into bottom mounting holes in display and
tighten all fasteners.
1
IMPROPER INSTALLATION CAN LEAD TO DISPLAY
(E, B) X4
Installation Instructions
(D) X2
