Remaining hazards
The machine has been built using modern tech-
nology in accordance with recognized safety
rules. Some remaining hazards, however, may
still exist.
• The splitting tool can cause injuries to fingers and
hands if the wood is incorrectly guided or support-
ed.
• Thrown pieces can lead to injury if the work piece is
not correctly placed or held.
• Injury through electric current if incorrect electric
connection leads are used.
• Even when all safety measures are taken, some re-
maining hazards which are not yet evident may still
be present.
• Remaining hazards can be minimized by following
the safety instructions as well as the instructions in
the chapter Authorized use and in the entire operat-
ing manual.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Release the handle button and switch off the ma-
chine prior to any operations.
• Avoid accidental starts of the machine: Do not
press the start button while inserting the plug into
the socket.
• Use the tools recommended in this manual to ob-
tain the best results from your machine.
• Always keep hands away from the work area when
the machine is running.

7. Technical data

Drive
Motor V/Hz
Input P1 W
Output P2 W
Operating mode
Motorspeed min
-1
Phase inverter
Dimensions D/W/H 1040 x 1000 x 2400 mm
Log length
Power max. tons*
Piston stroke
Forward speed cm/s
Return speed cm/s
Oil quantity l
Weight kg
Subject to technical changes!
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58

8. Unpacking

Open the packaging and remove the device carefully.
Remove the packaging material as well as the pack-
aging and transport bracing (if available).
Check that the delivery is complete.
Check the device and accessory parts for transport
damage.
In case of complaints the dealer must be informed
immediately. Subsequent complaints will not be ac-
cepted.
If possible, store the packaging until the warranty pe-
riod has expired.
Read the operating manual to make yourself familiar
with the device prior to using it.
Only use original parts for accessories as well as for
wearing and spare parts. Spare parts are available
from your specialized dealer.
Specify our part numbers as well as the type and year
of construction of the device in your orders.
m ATTENTION
The device and packaging materials are not toys!
Children must not be allowed to play with plas-
tic bags, film and small parts! There is a risk of
swallowing and suffocation!
9. Attachment / Before starting the
9.1 Mount (14) wheels (fig. 2)
Slide the wheel axle Through the drilled hole on the
bottom, rear end of the splitter.
Now insert the wheels on the wheel axle and fasten
HL1450
them with two splints.
E-motor
400V / 50Hz
9.2 Mount (2) controller handles (fig. 3)
4300
Insert the controller arm with slotted hole onto
the rocker switch (b) and the drilled hole onto the
3400
threaded rod (a) .
S6 40%
Secure the controller arm with a washer and fasten
1400
it with a spring splint pin on the rocker switch and a
yes
self-locking nut on the threaded rod.
Now fasten the other control arm on the other side in
accordance with the method described
1060 mm
14
9.3 Mount (12) holder arm (fig. 4)
860 mm
Insert both holder arms into the rectangular steel
9
tubes, which are located on the left side of the
6 splitter. Fasten the holder arms with two M10 x 45
mm hexagon screws and self/locking nuts each.
10
208
9.4 Mount (6) holder arm for trunk lifter (fig. 5)
Fasten the holder arm with two hexagonal screws
(M10 x 25) on the frame, but do not tension the screws
tightly yet. (more at 9.5)
equipment
GB | 21
