Installation Instructions:
Step 1:
Step 1 : Screw Pillar Installation
Screw on the four LGA2011 Type B Screw Pillars into the Heatsink studs on the ILM Assembly Frame
around the processor socket.
Step 2:
Step 2 : Anchoring Mount Installation
Place the Anchoring Mount onto the four LGA2011 Type B Screw Pillars, secure it by tightening it with 4
M3L6 Screws.
Step 3:
Step 3 : Applying Thermal Paste
Apply the Chill Factor III to the base of the Heatsink and the surface of the CPU evenly.
7
