Internal pole
11
Height adjustment ring
12
External pole
13
Cap
14
Base
15
Screw (mounting plate)
16
Control panel
17
Screw (grill)
18
Control panel (Fig. B)
ON / SPEED button
19
OFF button
20
LED sleep timer
21
LED speed setting
22
Remote control (Fig. C)
ON / SPEED button
23
TIMER button
24
MODE button
25
OFF button
26
Scope of delivery
Immediately after unpacking, check that all the
items are present and that the product is in perfect
condition.
2 Bases
1 Pole
4 Cross-head screws
1 Cap
1 Motor
2 Grill
1 Propeller
1 Blade cover
1 Rear grill locknut
1 Remote control
1 Set of assembly instructions and instructions for use
Technical data
Fan
Model number:
VE-6035SCR /
VE-6036SCR
Operating voltage:
220–240 V ∼, 50 / 60 Hz
Output:
45 W
Protection class:
II /
Fan power
consumption:
40.9 W
Power consumption
in standby mode:
0.37 W
Speed levels:
1000–1100–1250 rpm
(+ / -10 %)
Max. speed:
1250 rpm (+ / -10 %)
Max. air velocity:
3.03 m / s
Max. volumetric
flow rate:
3275 m³ / h (+ / -10 %)
(54,59 m³ / min)
Degree of oscillation: 85 °
Adjustable angle:
25 °
Height adjustable:
105–125 cm
Seasonal power
consumption:
13.5 kWh / a
Service value:
1.33 (m³ / min) / W
Fan sound
power level:
52.4 dB
Determination of
service value:
IEC 60879:1986
(corr. 1992)
Remote Control
Battery:
2 x AAA 1.5 V
(not included)
Max. range:
10 m
Protection class:
III /
Safety notes
DANGER TO LIFE
AND RISK OF ACCIDENTS
FOR INFANTS AND CHIL-
DREN! This product may be
used by children aged 8 years
and up, as well as by persons
with reduced physical, sensory
or mental capacities, or those
lacking experience and / or
GB/IE/NI
7
