TROUBLESHOOTING

The gate would not move, the buzzer is emitting an alternating sound for 1 minute, and one
of the LED is blinking red/green.
The gate would not move, the buzzer is emitting an alternating sound for 1 minute, and one
of the LED is blinking red/green,
OR
the gate is trying to open/close, but stops almost immediately, the buzzer is emitting an
alternating sound for 1 minute, and one of the LED is blinking red/green.
All of the LEDs on the MASTER Wi-Fi are OFF
During memorization of the safety devices the buzzer sounds for 3/5 second
During memorization of the safety devices the buzzer sounds 2 twice
When giving a command the buzzer sounds 3 times
When giving a command the buzzer sounds 4 times
The buzzer sounds 5 times when the strip connected to the photocell receiver is pressed
When giving a command the buzzer sounds 5 times
The buzzer emits a sound every 3 seconds and the blinker during the gate operation flashes 2
times in succession followed by a pause of 3 seconds for 1 minute and one of the dual-color
leds is ignited red fixed
The gate doesn't move, the buzzer emits a sound every 3 seconds and the blinker flashes 2
times in succession followed by a pause of 3 seconds for 1 minute and one of the dual-color
leds lights flashing red
LED DL2 is off and one of the dual-color LED EDGE emits a constant green light
Led light DL2 on, Led light DL3 off. Giving a command one of the EDGE LED lights up and
blinks green/red, the gate does not move, and the buzzer emits an alternating tone for 1
minute.
OR
the gate starts to open / close and then stops, the buzzer emits an alternating tone for 1
minute.
The buzzer does not sound when the batteries are removed from the strip
The door does not open or close and one of the dual-color LEDs emits a constant green light - Photocell is not aligned or it is engaged. The batteries in the photocell transmitter are
The door does not open or close, the buzzer emits a sound every 3 seconds and the blinker
flashes 2 times in succession followed by a pause of 3 seconds for 1 minute and one of the
dual-color LEDs lights flashing red
The strip connected to the photocell transmitter or receiver does not work as a safety device Check the correct setting of the jumper of the photocell transmitter/receiver. If the jumpers are
PROBLEM
If two MASTER Wi-Fi, installed at a distance of about 20 m from one another, are commanded
simultaneously, their communication and check signals with the accessories can overlap and
interfere with each other, causing the systems to go into alarm. Move the two MASTER Wi-Fi
away from each other over the 20 m.
Failed control between MASTER Wi-Fi and the safety accessories, either the photocells or
the safety edges:
- Install the 868MHz aerial (code ACG5451) on the MASTER Wi-Fi to guarantee the correct
communication between the MASTER Wi-Fi and the safety accessories installed.
Attention: The aerial must be placed in sight of all the safety accessories installed.
If the indication of failure persists, check the level of charge of the batteries, and if not
adequate, replace them.
Ensure that 12 or 24 V ac/dc power is present to the power feed terminals of the MASTER
Wi-Fi
It has been tried to memorize a safety device with wrong microswitch.
Verify that the dual-color led that flashes on MASTER Wi-Fi corresponds at the safety device
microswitch to memorize.
A safety device is already in the memory
- No safety device has been memorized, memorize at least one, OR
- The DIP corresponding to the safety devices memorized on the MASTER Wi-Fi card are OFF.
Turn them to ON
Possible cable missing between the MASTER Wi-Fi and the door control card:
- Blinker to card connection wires detached, OR
- Strip to card connection wires detached, OR
- Photocell to card connection wires detached, OR
- Radio control for pedestrian gate opening not completely closed
Contact configuration error with the strip connected to the photocell receiver
- Resistance not connected in series with the N.C. contact of the strip connected to the
photocell receiver, OR
- Wires detached on the strip with N.O. contact, OR
- Resistance not connected in series with the N.C. contact of the strip, OR
- Wires detached on the strip with N.O. contact connected to the photocell receiver
Replace the batteries of the photocell(s) or the strip(s) as they are low
Replace the batteries of the photocell(s) or the strip(s) as they are exhausted
- Wires detached on the strip with N.C. contact, OR
- Ensure that there is resistance of 8,2KΩ in series with the N.O. contact of the strip connected
to the photocell receiver
MASTER programmed only with safety edges TOUCH Wi-Fi. Remove the MASTER black wire
from the photocell contact on the control panel, and if there are no hard-wired photocells
installed, put a jump-link between the photocell and common contacts on the control panel.
Ensure that the micro-switch on the MASTER Wi-Fi corresponding to the strip is in the ON
position
exhausted, OR
- Resistance of 8,2KΩ is not connected in series with the N.C. contact or in parallel with the
N.O. contact of the strip connected to the photocell transmitter, OR
- Resistance of 8,2KΩ is not connected in parallel with the N.O. contact of the strip connected
to the photocell transmitter
Photocell or strip receiver batteries are exhausted
correctly setting, remove and put again the batteries.
