2

Mounting and installation

Note
You will need 4 new AA batteries (mignon) for commissioning later.

2.1 Wiring diagram

Fig. 2: Wiring diagram
3 Lock
4 Outer fitting
5 Inner fitting
7 Battery holder
8 Ribbon cable
D00396
01
4
Mounting and installation
8
5
7
3
