2.3 Optional: Door lock – example: effeff 309X
Information
In these instructions, we describe the following as examples:
1. Door lock 309X
2. Door DIN left
3. Wooden and steel doors
Caution
The door may be locked unintentionally during assembly
The lock locks automatically when the door is closed.
You may then no longer be able to open the door from the
outside.
Extend the lock bolt before assembly.
 At the same time:
Press the control latch and the lock latch.
 Hold the control latch pressed.
 Release the lock latch.
 The lock latch will extend.
D00396
01
