Security Fitting - Assa Abloy ANYKEY Code Montageanleitung

Access Control

2.5 Security fitting

Preparation
 On the outer fitting:
Screw the 3 threaded pins fully into the screw sockets.
 Drill all holes as shown in Fig. 3.
 Optional:
Mount the decorative plate.
Feeding through the ribbon cable
 Push the connector of the ribbon cable into the insertion sleeve.
 Push the insertion tool through the top fixing hole.
Page 24 D00396
