Programming
The menu Sensor visualization is selected.
With the button  you will switch off the visualization (
With the button  you will switch on the visualization (
When the visualization is switched on a selectable receiver will
be shown. Only receivers with programmed sensors will be
shown.
With the button  you will move to the selected receiver.
With the button  and  you can chose another receiver.
The selected receiver will move shortly.
With the button
ment without saving the modifications.
With the button
get back into the menu Adjustment.
8.7. Sensor parametrization
With the sensor parametrization the values of the automatic and protection function,
that are released by the commeo Sensor WS/WSRF, are shown and set. T he values can
be shown and set individually for each receiver. The description of this function and
their setting can be found in the commeo Sensor WS/WSRF instruction under point
7. Function.
This instruction describes the query of the sensor information only.
After selection of a receiver with programmed sensor all existing information can be
shown in the menu Sensor information. Not all receiver profiles are using all sen-
sors. Not used or existing sensors will not be shown in the receiver information. The
following displays are possible:
Sensor status
A sensor is programmed and ready for operation.
A sensor is programmed and the test mode is running.
N o signal can be received from the programmed sensor (sensor loss).
Wind
The wind sensor in the receiver is active.
The wind sensor is active and the receiver is in wind alarm.
Rain
The rain sensor is active.
The rain sensor is active and announces rain.
Frost
The frost sensor is active.
T he frost sensor is active and has exceeded the set threshold (frost alarm).
you will get back into the menu Adjust-
you can save the modifications and will
57
).
).
