9.3 Battery replacement


Before opening the BENNING CFlex 1, make sure that it is free of voltage!
Electrical danger!
The BENNING CFlex 1 is supplied by means of two 1.5 V batteries of type AAA (IEC LR03).
Battery replacement (see figure 4) is required, if the red LED (battery indication) 6 lights.
Proceed as follows to replace the batteries:
- Remove the BENNING CFlex 1 from the object to be measured.
- Disconnect both safety plugs of the safety measuring lead from the multimeter.
- Switch the rotary switch  to position "OFF".
- Put the BENNING CFlex 1 face down and unscrew the screw of the battery compartment
cover 7 .
- Lift off the battery compartment cover (in the area of the housing slots) at the bottom part of
the battery compartment.
- Replace the exhausted batteries by two new ones of type AAA (LR03). Make sure that the
new batteries are inserted with correct polarity!
- Place the battery compartment cover onto the bottom part and tighten the screw.
See figure 4:
Make your contribution to environmental protection!

Do not dispose of discharged batteries in the household garbage. Instead, take
them to a collecting point for discharged batteries and special waste material.
Please inform yourself in your community.
9.4 Calibration
Benning guarantees compliance with the technical and accuracy specifications stated in the
operating manual for the first 12 months after the delivery date.
To maintain the specified accuracy of the measurement results, the instrument must be recali-
brated at regular intervals by our factory service. We recommend a recalibration interval of one
year. Send the unit to the following address:
Benning Elektrotechnik & Elektronik GmbH & CO. KG
Service Centre
Robert-Bosch-Str. 20
D - 46397 Bocholt

10. Environmental note

At the end of the product's useful life, please dispose of the device at collection points
provided in your community.
04/ 2019
Battery replacement
BENNING CFlex 1

10
