7902 - 7905 | Installation and Operational Manual

Technical specifications

Alarm/Action Box
Power supply
Contact rating action relay
Alarm input trigger threshold
System connectors
System cable
PIR angle of sight
• horizontal
• vertical
Dimensions
• without PIR
Ambient conditions
Temperature
• operating
• storage
Humidity
• operating
• storage
Specifications may be changed without notice.
Bosch Security Systems | 2004-06
through the system cable (24V
30V, 5A AC/DC
> 150 Ohm (N.C. input)
< 150 Ohm (N.O. input)
RJ11E modular ('telephone'
connectors)
4-wire dual twisted pair cable e.g.
VSS2906/00 or VSS2930/00
110º
20º
119 x 77 x 40 mm
Ammonia resistant
+10ºC - +45ºC
-25ºC - +70ºC
20... 90%RH
20... 99%RH
| 163
Installation and Operational Manual Technical Specifications
)
DC
