LASER DISTANCE METER
EN
Addition/subtraction
Turn on the laser beam. Aim the product at
Short press
measured object.
Take the first measurement. Measuring result
Short press
appears in the main line.
Short press
The symbol of addition
for addition or
will appear on the display.
for subtraction
Turn on the laser beam. 1st measurement moves
Short press
to the 2nd line.
Short press Take the second measurement.
- 1st measurement
- 2nd measurement
- result of addition/subtraction
To do addition/subtraction of more than 2 measurements short press
and perform the above mentioned operations required number of times.
Short press Exit the mode.
12
Vector 100 CONDTROL
User manual
or subtraction
LASER DISTANCE METER
EN

CALCULATIONS

Area
Short press
Enter menu of functions.
1 time.
Short press / Select function "Area"
Symbol
Short press
Laser beam is on.
Short press Make the first measurement (length).
Short press Make the second measurement (width).
- length
- width
- area
Short press Exit the mode.
Vector 100 CONDTROL
User manual
will appear on the display.
13
