LASER DISTANCE METER
EN
Power supply
Dimensions
Weight
* Use a reflective plate to increase the measurement range during daylight or if the
target has poor reflection properties.
** Accuracy can decrease in unfavorable conditions, such as intense sunshine or
when measurements are made against glossy or transparent surfaces, moving
objects, objects with rough surface.
In unfavorable conditions or when measured distance is over 100 m the maximum
permissible accuracy is calculated in the following way:
± (Y + 0,25хDх10-3) mm, where
D (mm) - measured distance
Y (mm) - permissible accuracy according to technical data.

PRODUCT DESCRIPTION

Display
3 5
7
4
1
6
Vector 100 CONDTROL
User manual
3.7 V 850 mAh Li-ion
rechargeable battery
119*46*28 mm
0.1 kg
1. Main line for displaying
measuring results
6
2. Additional lines for
displaying measuring results
3. Indication of tilt angle
4. Indication of the mode
2
5. Indication of Bluetooth
6. Indication of battery charge
level
7. Indication of reference point
8
8. Indication of measuring unit
LASER DISTANCE METER
EN
1
2
6
1. Display
2. Keyboard
3. A hole for the strap
4. End-piece
5. Tripod thread 1/4''
6. Mini-USB connector for charging
Vector 100 CONDTROL
User manual
5
4
3
7
