LASER DISTANCE METER
EN
Functions of buttons
Button Short press
Switch on the device
Switch on the laser beam
Single distance measurement
Subtraction
Down (in menu of functions)
Set response time in timer (decrease value)
Flip through measuremens in memory
(backwards)
Addition
Up (in menu of functions)
Set response time in timer (increase value)
Flip through measurements in memory
(forward)
Enter the menu
Stop measurement/clear/exit the mode/exit
the menu
+
Select measuring unit
simultaneously

OPERATION

Battery charging
Charge level is shown on display. Charge the battery when symbol
on the display. Use USB charger delivered in the set only. It is not recommended
to use the product while charging. It takes approximately 3 hours to fully charge
the batteries.
8
Vector 100 CONDTROL
User manual
Long press
Continuous
measurement
(tracking)
Change
reference point
Switch off the
device
appears
LASER DISTANCE METER
EN
Switch on/off the device
To switch on the device short press
To switch off the device press and hold
Measuring unit
Short press and
Short press buttons and
unit – m/ft/in. Short press
measurement mode.
Reference point
Press and hold button
point. Appropriate indicator will appear on the display.
- Front - Tripod
- Rear (default) - End-piece
Menu
Short press button to enter
the menu of functions:
Short press buttons (down),
(up) to select the function. Selected
function will be framed in grey color.
Short press to confirm. Selected
function will be activated.
Short press to exit the menu.
Vector 100 CONDTROL
User manual
.
during 1 second.
simultaneously.
to select required measuring
to confirm and return to single distance
during 1 second to select the reference
9
