Follow these advises to adjust the azimuth:
measurement
L – R (Track 1)
R – L (Track 2)
L – R
R - L
L - R
R - L
Note:
The measurement values in the table are only used as examples and can be different
depending on the type of cartridge.

5. Technical data

Operating Voltage:
In- and Outputs:
Phono-unit:
Amplification:
Channel separation:
Distortion factor: (THD+N):
Input impedance/Capacity:
Output impedance:
Frequency response:
RIAA:
Headphone output:
Amplification:
Headphone impedance:
Connection:
Measurement unit:
Indication range:
Noise filter:
Dimensions: H x W x D
Weight:
Page / Seite 7
Left channel Right channel
(display) (display)
0 -30dB
-30dB 0
0 -35dB
-25dB 0
0 -25dB
-35dB 0
24V DC stabilised with power supply
Input: 100-240V~ / 47-63Hz
RCA-sockets, unsymmetrically
> 80dB
MC = 400Ohms / 220pF
100Ohms
RIAA +/- 0,5dB deviation
100 – 600 Ohm
6,3 mm-bushing
-50 till +6dB, accuracy +/-0,2dB
Gauge-measurement up to max. 19,99mV
from 200Hz / transconductance 12dB per octave
(valid only for right channel when unit is in
measurement use)
47 x 102 x 190mm
Azimuth Optimizer: 750g
Power supply: 150g
Azimuth Optimizer
Direction of
cartridge-rotation
Azimuth is O.K.
Rotate cartridge
clockwise
Rotate cartridge
counter clockwise
MM = 40dB, MC = 60dB
< 0,01% / 1kHz
MM = 47kOhms / 220pF
20Hz – 70kHz /-3dB
10dB
User manual / Bedienungsanleitung
