1. List of components

Azimuth Optimizer

The Clearaudio
designed for this product. We recommend you store this original packing and to use this
packing in case of any transportation. Please check if the parts listed below have been
enclosed:
Azimuth Optimizer
1
Power supply adaptors ( 1 x US;1 x
3
UK, 1 x Europe)
5
Phonostages are devices designed to provide a very high level of amplification. This is
necessary because the electrical signal generated by a phono cartridge is extremely low
(usually less than one-thousandth of a volt). The job of the phonostage is therefore to
accurately equalise the phono signal and boost it to line level (measured in volts).
However, phonostages are by nature extremely sensitive, which leads to the potential
problem that high-frequency interference may also be amplified to a point at which it
becomes noticeable.
Unfortunately it is not possible to completely protect the sensitive phonostage circuitry from
this interference without degrading its high fidelity performance. Therefore care must be
taken to position the phonostage away from sources of high frequency interference such as
mobile phones, modems and powerline communication systems (PLC) in which data is sent
over the mains power network.
Page / Seite 3
has left our factory in safe packing that has been specially
Unit

User Manual

Azimuth Optimizer
Power Supply (this wide scope
2 power supply enables worldwide
usage)
Azimuth Optimizer
clearaudio
4
test record
6 Warranty & Registration Card
User manual / Bedienungsanleitung
clearaudio electronic GmbH 2016
