Battery Powered; Front Panel Keys And Indicators; Function Of The Keys - PCE Instruments HLD150 Bedienungshandbuch

3.2 BATTERY POWERED

The weighing indicator can be operated from the battery if desired.
When the battery needs charging the
when the symbol is on. The scale will still operate for about 10 minutes after which it will automatically switch off to protect
the battery.
To charge the battery simply plug into the mains power. The scale does not need to be turned on.
The battery should be charged for 12 hours for full capacity.
You can find the
the mains power the internal battery will be charged. If the symbol is full the battery has a full charge. If it is half the
battery is nearly discharged and empty indicates the battery should be charged.
As the battery is used it may fail to hold a full charge. If the battery life becomes unacceptable then contact your distributor

4. FRONT PANEL KEYS AND INDICATORS

FUNCTION OF THE KEYS

symbol on the weight display will be empty. The battery should be charged
symbol on the display to indicate the status of battery charging. When the scale is plugged into
- It turns on/off the scale.
- Clears the displayed gross weight if it's within +/- 2% of the total capacity.
- A secondary function of "Enter" key when setting parameters or other functions.
- If pressed for an instant it executes the semiautomatic tare.
- A secondary function of incrementing the active digit or selecting a value or
parameter when in setting mode.
- If pressed for an instant it allows linking a weight to the 100 percentile (see section
6.7).
- In the numeric input, it selects the digit to be modified, from left to right.
- If pressed for an instant it allows to execute the reference operation (see section
6.6)
- In the numeric input, it selects the digit to be modified, from right to left.
6
