P CONT
In this transmission mode the instrument transmits continuously the following data format depending on the functioning
mode:
Totalisation Mode
ST,GS,XXX.XXXXkg<CR><LF>
<CR><LF>
Counting Mode
PCS:XXXXXXXXpcs<CR><LF>
<CR><LF>
Percentage Mode
PERC:XXXXX.XX%<CR><LF>
<CR><LF>

8.2 SERIAL COMMANDS

Extended weight read command
[CC]REXT<CR LF>
in which: [CC]
<CR LF>
Instrument response:
[CC]B,hh,NNNNNNNNNN,YYTTTTTTTTTT,PPPPPPPPPP,uu <CR LF>
in which: [CC]
B
,
hh
,
NNNNNNNNNN
,
YY
TTTTTTTTTT
,
PPPPPPPPPP Number of pieces on 10 characters, equal to 0 if the indicator is in a functioning mode other
Percentage of weight
<CR><LF>
GS for gross weight, NT for net weight, XXX.XXXX is the weight
XXX.XXXX is the Number of pieces
XXXXX.XX is the Percentage of weight
instrument address in the format of two ASCII decimal digits
just in case the address mode is selected in the step F4 (FOR EXAMPLE 01)
Carriage Return + Line Feed (ascii decimal character 13 and 10).
instrument address in the format of two ASCII decimal digits
just in case the address mode is selected in the step F4 (FOR EXAMPLE 01)
scale number (always 1).
Comma character
UL Underload
OL Overload
ST Stability of display
US Instability of display
TL Active inclination input
Comma character
net weight on 10 characters including possible sign and decimal point
Comma character
"PT" if the tare is manual, otherwise YY = " " (two empty spaces) if the tare is semiautomatic.
Tare weight on 10 characters including possible sign and decimal point.
Comma character
