m Residual risks
The machine has been built using modern technology
and in accordance with recognized safety rules.
Some hazards, however, may still remain.
• Risk of injury to fingers and hands from the tool in
operation during improper use.
• Electrical hazards when unsuitable electric con-
nections are used.
• Safety hazard from the hedge clippers in case of
long hair and loose clothing; Wear personal protec-
tive equipment such as a hair net and tight work
clothing.
• Although having regarded all considerable rules
there may still remain not obvious remaining haz-
rds.
• Minimize remaining hazards by following the in-
structions in "Safety Rules", "Use only as author-
ized" and in the entire operating manual.

6. Technical data

Cutting circle diameter mm
Bar length mm
Cutting length mm
Max. cutting speed max.
min
-1
Engine V / Hz
Engine output W
Weight kg
Subject to technical changes!
Information concerning noise emission measured ac-
cording to relevant standards:
Sound pressure L = 84,4 dB(A)
pA
Sound power L = 96 dB(A)
WA
Uncertainty K = 3 dB(A)
PA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Vibration front handle A = 2,839 m/s
hv
Vibration rear handle A = 2,975 m/s
hv
Uncertainty K = 1,5 m/s
2
PA
Warning!
The specified vibration value was established in ac-
cordance with a standardized testing method. It may
change according to how the electric equipment is
used and may exceed the specified value in excep-
tional circumstances.
The specified vibration value can be used to compare
the equipment with other electric power tools.
The specified vibration value can be used for initial
assessment of a harmful effect.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
20
660
600
1600
230 - 240 V ~ / 50
620
3,6
2
2
Reduce noise generation and vibration to a minimum!
• Use only equipment that is in perfect condition.
• Maintain and clean the equipment regularly.
• Adopt your way of working to the equipment.
• Do not overload the equipment.
• Have the equipment checked if necessary.
• Switch off the equipment when not in use.
• Wear gloves.

7. Attachment and operation

ATTENTION!
Before working on the device - cleaning, inspection,
maintenance or other work - always turn off the de-
vice and separate it from the power supply.
ASSEMBLY
Mounting the protective cover Fig. 3
Attach the hand guard (2) with 2 screws to the device
prior to startup.
m Warning!
Use only original manufacturer's replacement parts,
accessories and attachments. Failure to do so can
cause poor performance, possible injury and may
void your warranty. Never use the machine without
the guard assembled!
Mounting of the extension cable (Fig. 4)
Plug the female connector of the extension cable on
the male connector of the device.
Thread the extension cable through the cable hook
(7) as a loop and hang it up.
Make sure that the extension cable has enough free
motion.
Do not use an electric tool with a defective
switch. An electric tool that cannot be switched
on or off is dangerous and must be repaired.
Starting and stopping the hedge trimmer, Fig. 5
Starting the device: Push the trigger (6) on the back
handle (5) and operate at the same time with the oth-
er hand the switch button on the front handle (4).
Stopping the device: Let go one of the trigger (6 or 4).
Back handle twist around 90° Fig. 7
m Please remove the electricity plug from the net-
work.
For twist the back handle please look for a safety
standing or lay the device on a plane surface.
Push the button (Pos. 8) until the end of the button
to the direction of the back handle. Afterwards you
can twist the back handle around 90°. (Please notice,
if you actuate the trigger (Pos. 6) it's not possible to
actuate the button (Pos. 8)
