RGP 150-15 - GB Seite 10 Freitag, 19. September 2003 11:56 11

Tool Specifications

Power surfacer
Nom. power requirement
Rated rpm
Surfacer head diameter
Weight
Protection class

Operating controls

1 Vacuum connection
2 Handle
3 On/Off switch
4 Lock-on lever
5 Extraction shroud/base plate
6 Venting slots
7 Dial control for speed preselection
8 Auxiliary handle
9 Retaining bracket
10 Suspension eyelet for balancer
11 Adjustment knob for base plate/ depth-of-cut
adjustment
12 Bolt hole
13 Pin
14 Socket spanner (size 10 mm)
15 Clamping bolt
16 Grinding head
17 Spindle
18 Fitting key
19 Extractor
20 Stud bolt
21 Inner ring
22 Washer
23 Gear wheel
24 Bearing pin
25 Vibration damper
Not all of the accessories illustrated or described are
included as standard delivery.

Special accessory*

"Point-shaped" grinding head
"Flat-shaped" grinding head
"Pyramid-shaped" grinding head PZ-RGP 150
Diamond grinding head
Carbide-tipped grinding head
Grinding wheels "pointed"
Grinding wheels "flat"
Grinding wheels "pyr.-shaped"
Spare disc
Spare disc
Balancer cable
Extractor
Socket spanner
*Not included in the scope of delivery
10
GB

Intended Use

The machine is intended for removal of plaster, coat-
RGP 150-15 E
ings, tile remainders, carpet-adhesive remainders, for
1500 W
roughing of concrete surfaces, smoothing of formwork
1000 - 2200 rpm
changeovers and planing of plaster flooring in con-
150 mm
5,2 kg struction.
II /
The machine is only for dry machining operation in
conjunction with a powerful extraction system.
The user alone is responsible for any liabilities caused
by usage other than intended.
Notes on Safety
For further notes on safety refer to enclosed sheet.
Always check the machine, cable and plug before
using. Have damages repaired only by a qualified
professional.
The machine must not be damp and must not be
operated in a wet environment.
Connect machines that are used in the open via a
residual current device (RCD) with an actuating
current of 30 mA maximum. Use only extension
cables that are approved for outdoor use.
The dust that is produced while working is detri-
mental to health. Use dust extraction and wear a
dust mask.
Wear safety glasses, hearing protectors and protec-
tive gloves.
Do not work with materials containing asbestos.
Before changing the grinding tool or performing
other work on the machine, pull the mains plug from
the socket.
Make sure the machine is switched off before insert-
ing the plug into a socket.
Always direct power cable to rear away from the
SZ-RGP 150
machine.
FZ-RGP 150
Always ensure that you have a secure footing while
working.
DIA-RGP 150
Always use the auxiliary handle (8) if possible.
HW-RGP 150
HW-SZ 35
HW-FZ 28
HW-PZ 21
DIA 150/SC
HW 150/SC
Balancer 2.4
RT-RGP 150
FK-SW10 RGP 150
This machine can only be operated
safely when the operating and safety
instructions are completely read and
strictly observed.
