Taurus ULTRA TRAINER Montage- Und Bedienungsanleitung Seite 40

Nr. Bezeichnung (ENG)
D2 SPONG HDR Φ23X3TX130MM
D3 FOAM SPACER RING
D4 PLASTIC PIPE
D5 HANDLE PULSE RING
Φ31.8X30.5MM
D6 SPACER RING Φ25.4
D7 HANDLE PULSE RING Φ31.8X22MM
D8 UPPER HANDLE PULSE HOUSING
D9 LOWER HANDLE PULSE HOUSING
D10 HANDLE PULSE
D11 SCREW M3X10MM
D12 SCREW M3X10MM
D13 SCREW M3X10MM
D14 TOGGLE COVER L2
D15 TOGGLE COVER L1
D16 PC BOARD LOAD -
D17 TOGGLE LOAD -
D18 TOGGLE COVER R2
D19 TOGGLE COVER R1
D20 PC BOARD LOAD +
D21 TOGGLE LOAD +
E8 BEARING 6003ZZ (TPX)
E11 WASHER M6XΦ19X2T
E12 SCREW M6X10MM
E13 SPACER RING M8X6T
E14 BEARING 6201ZZ
E15 SCREW M5X6MM
E16 NUT M8
G CONSOLE
G1 SCREW M5X15MM
G3 SENSOR WIRE 450MM
G4 SENSOR WIRE 450MM
G6 SENSOR WIRE
H1 PEDAL
40
Anz. Nr. Bezeichnung (ENG)
2 H2 CUSHION PAD
2 I ADAPTOR
2 J1 SCREW M10X150MM
2 J2 SCREW M10X20MM
2 J3 WASHER Φ3/8"
2 J5 SCREW M6X12MM
2 J9 WASHER M8
2 Z1 PACKING TUBES (UPPER)
4 Z2 SCREW M8X50MM
4 Z3 END CAP 30X60MM
4 M1 IDLER WHEEL PLATE (6T)
2 M2 IDLER WHEEL
1 M3 BEARING 6001 (TPX)
1 M4 BUSH Φ12.05XΦ16X10.5
1 M5 SCREW M10X23MM
1 M6 SCREW M12X35MM
1 M7 C CLIP R28
1 M8 NUT M8
1 M9 SCREW M8X75MM
1 M10 NUT M10
2 M11 SCREW M5X20MM
2 M13 NUT M5
2 M15 NUT M12
8 M16 NUT M5
4 M17 SCREW M5X12MM
8 M18 MAGNETIC
4 M19 MAGNETIC HOUSING
1 M20 SCREW M5X8MM
4 M25 SCREW M4x12MM
1 M26 BEARING 6201ZZ TPX
1 M27 PULLEY Φ40
2 M28 AXLE
2 M29 BEARING 6001 TPX
ULTRA TRAINER
Anz.
2
1
1
4
4
8
4
2
4
4
1
1
1
1
1
1
1
1
1
2
1
2
4
6
1
10
1
2
4
1
1
1
2
