Specification - Peiying PY9909.2 Bedienungsanleitung

SPECIFICATION:

Technical parameters
• Max. power: 4 x 40 W
• RMS power: 4 x 25 W
• S/N ratio: >55 dB
• Channel separation: >55 dB
• Frequency response: 16 Hz-25 kHz
• Power supply: 10,8-16 V DC
• Load impedance: 4 Ω
• Fuse: <10 A
Display
• Size: 7"
• Panel: TFT
• Resolution: 800x480 px
• Touchscreen: Resistive
• Display brightness: Adjustable
• Panel tilt angle: Adjustable
Main features
• Size: 1 DIN
• Supported formats
• Audio: MP3, AAC, WMA, FLAC, WAV
• Video: MP4, DIVX, AVI, RMVB, MKV
• Picture: JPG, PNG, GIF
• Panel: detachable
• Equalizer: Pop/Rock/Classic/Flat/Jazz/Electro/User
• GPS: Yes
• Operating system: WIN CE 6.0
• RAM: 64 MB
• Supported standard: PAL/NTSC
• Steering wheel control: Yes (analogue)
• Tone controls:
• Bass (at 100 Hz): ± 7 dB
• Treble (at 100 kHz): ± 7 dB
• Keys backlight: RGB
• Microphone: Yes
• App compatibility: Android 5.0 and later
Bluetooth
• Version: 2.1
• Phone call management: Yes
• Phonebook synchronization: Yes
EN
• Audio streaming: Yes
Analogue radio tuner
• FM frequency range: 87,5 - 108 MHz
• AM frequency range: 522 – 1620 kHz
• FM preset memory: 18
• AM preset memory: 12
• RDS: Yes (AF/TP/TA/EON/PTY)
• Frequency search: automatic / manual
• Stereo separation: >40 dB
30
Owner's manual
