Setting up

Connecting the cables

Connect the external hard disk to your computer using a free USB port or an exter-
nal SATA connection.
The difference between those two ports is the transmission speed.
Using a USB 1.1 port instead of a USB 2.0 port means a slower transmission speed.
The external SATA connection offers a faster transmission speed than through USB.
1. Start your computer and wait until Windows
2. Connect the USB cable to the USB connection on your external hard disk.
Or
Use a suitable eSATA cable (not included) if your PC has an external SATA in-
terface.
3. Connect the other end of the connection cable to your computer.
4. Now connect the power adaptor to a power socket that can easily be reached.
Plug the rounded DIN end of the power adaptor into the corresponding
socket in the hard disk.
5. The operating indicator (blue LED) will light up as soon as the hard drive is
connected to a source of electricity.
6. With Windows
connected.
Electrical USB
connection connection connection
®
XP/Vista the hard disk is now automatically recognized and
Setting up
eSATA
®
has been fully loaded.
(Back view)
7
