Noise Level; Vibration Level - Fort HYDRO Bedienungs- Und Wartungsanleitung

ENGLISH
PTO clutch: by belt tension.
Speed: from 0 to 6,2 Km/h forward and from
0 to 3 Km/h in reverse; speeds are
referred to machine with tyre 4.00x10"
and do not change with front or rear
attachments; if required reverse speed
could be adjusted to reduce speed.
Tyre: standard 4.00x10"; if required the
following tyre options available:
16x6.50x8"; 18x9.50x8"; with iron
cage and twin tyre application. For
particular need during winter
maintenance snow chain option
available.
Parking brake: the machine automatically stops
when the control lever (C) is released
and acts as your parking brake.
Weight:
with Intermotor LGA 280 engine
with Intermotor LGA 340 engine
with Honda GX 270 engine
with Lombardini 15LD 350
Main dimension: Main dimension of machine in
standard version are described in fig. 3.
1.5 INTERCHANGEABLE ATTACHMENTS
The walking-behind tractor can be equipped with
different attachments in order to work in various
applications in point 1.3 described.
1.5.1 FRONT ATTACHMENTS
- Mowing bar - sickle
- Grass cutter - flail
- Leaf suction
- Verticut - Aerator
- Lawn mower
- rotary
- Scrub cleaner
- Front or side sweeper
- Snow thrower
- Snow blade
1.5.2 REAR ATTACHMENT
- Rotary tiller
- Rotating harrow
- Stoneburier
- Tow behind trailer
- Tank trailer
- Irrigation or sprayer pump

1.6 NOISE LEVEL

Noise level was measured with unloaded machine with
engine at 3000 rpm with no attachments coupled as
per 77/311/CEE directive.
The continuous acoustic level A at driver's ear are as
follows:
Intermotor LGA 340 engine:
Honda GX 270 engine:
Lombardini 15LD 350:

1.7 VIBRATION LEVEL

Vibration level was measured with machine in same
conditions of previous paragraph 1.6, value recorded
are as follows:
Intermotor LGA 340 engine:
Honda GX 270 engine:
120 Kg
Lombardini 15LD 350
123 Kg
116 Kg
127 Kg
We remind You that noise and vibration level could
also change dramatically with addition of coupled
attachments.
1.8 REFUELLING PROCEDURE
Engine
Engine is supplied without oil, oil type and quantity
to add before start-up should comply with use and
maintenance manual instructions. Also for fuel type
make reference to use and maintenance manual, and
engine plate. Oil level should be checked daily.
Pump and engine hydrostatic group
The machine is supplied with 1,1 lt oil SAE 20W/50.
Level control should be checked daily and should
reach level indicated on expansion tank (6 fig. 1). Oil
replacement should be each 300 working hours
following and at least one time a year.
Differential group
During assembly oil lt EP 320 is added and needs
maintenance only in case of oil leak. Replacement after
indicative check each 500 working hours.
Leq 83,8 db (A)
Leq 82,5 db (A)
Leq 89,5 db (A)
LwA 105 db (A)
3,2 m/sec
3,1 m/sec
4,5 m/sec
ATTENTION
25
