3 Use
CAUTION
!
If the housing or any of its attached parts is
damaged (e.g. the connecting plug), the equipment
must be taken out of service immediately and
secured against being inadvertently switched on
again.
The pressure-tight housing may only be opened by
the manufacturer or by a person authorised by the
manufacturer.
Establish the earth bonding using the earthing
screw on the housing. This must be done with
a cable lug and a cable with a cross-section of at
2
least 4 mm .
The X-zone Switch Off/On may only be operated
with a 400 V 3 phase+N 50 Hz input.
The intrinsically safe alarm input to the X-zone
Switch Off/On may only be made in conjunction
with the X-zone 5000 while complying with the
intrinsically safe characteristics (see Instructions
for Use for the Dräger X-zone 5000).
If several active devices are connected together in
an intrinsically safe circuit, other safety-related
values may arise. The intrinsic safety may be
compromised as a result.
Set up the equipment securely on a level surface.
Stress on the connecting and interconnecting
cables should be avoided.
Never bypass the safety devices or take them out
of operation.
Before use, examine the connecting cable for
defects or ageing.
When running the connecting cable, take care that
it does not get crushed or kinked and that the
connector does not get wet.
3.1

Preparation for use

CAUTION
!
Only connect consumers that do not exceed the
following maximum values: 400 V; 50 Hz; CEE 32A;
3P+N+PE.
In connection with the connecting socket, only plugs of
the type 8571/12 and 8578/12 R. STAHL may be used.
1. Switch the X-zone 5000 on according to the Instructions for
Use.
2. Connect the cable (10) on the X-zone Switch Off/On to a
suitable power supply point, e.g. the main distribution box.
Operating LED lights yellow.
3. Connect the switch relay cable (7) to the switch relay on the
X-zone 5000.
X-zone Switch Off: Power supply LED is off.
X-zone Switch On: Power supply LED is off.
4. Connect the explosion-protected CE plug of the consumer
to the socket (9) on the X-zone Switch Off/On.
Dräger X-zone Switch Off/On
NOTICE
i
i
The rotary switch is equipped with a safety lock and
can be turned only if an explosion-protected CE plug is
connected.
5. Turn the rotary switch (8) to position 1.
6. Check all connectors are connected correctly.
3.2 Switch on the X-zone Switch Off/On
X-zone Switch Off:
1. Connect the equipment according to Chapter 3.1 .
2. Press the emergency off switch (2) and unlock it with
the key (3).
The outgoing power supply is switched on and the power
supply LED lights green.
3. Carry out a functional test (see Chapter 3.4 on Page 9).
X-zone Switch On:
1. Connect the equipment according to Section 3.1.
2. Carry out a functional test (see Chapter 3.4 on Page 9).
3.3 Switch off the X-zone Switch Off/On
1. Turn the rotary switch (8) to position 0.
2. Disconnect the loads from the sockets (9) on the X-zone
Switch Off/On.
3. Disconnect the switch relay cable (7) from the switch relay
on the X-zone 5000.
X-zone Switch Off: Power supply LED goes out.
X-zone Switch On: Power supply LED is off.
4. Disconnect the cable (10) on the X-zone Switch Off/On
from the suitable power supply point, e.g. the main
distribution box.
Operating LED goes out.
5. Switch off the X-zone 5000 according to the Instructions for
Use.
3.4

Functional test

CAUTION
!
Perform a functional test before every start-up!
X-zone Switch Off:
1. Connect the equipment according to Chapter 3.1 .
2. Initiate the test alarm on the X-zone 5000.
The outgoing power supply is interrupted and the power
supply LED goes out.
3. Press the emergency off switch (2) and unlock it with
the key (3).
The outgoing power supply is switched on and the power
supply LED lights green.
X-zone Switch On:
1. Connect the equipment according to Section 3.1.
2. Initiate the test alarm on the X-zone 5000.
The outgoing power supply is switched on and the power
supply LED lights red.
3. Press the reset button (11).
The outgoing power supply is switched off and the power
supply LED goes out.
Use
9
