Technical Data; Order List - Dräger X-zone Switch Off Gebrauchsanweisung

7

Technical data

7.1 X-zone Switch Off
Dimensions:
Weight:
Ambient conditions:
(during operation
and storage)
Protection class:
Power consumption:
Electrical supply:
Input side
Output side
7.2 X-zone Switch On
Dimensions:
Weight:
Ambient conditions:
(during operation
and storage)
Protection class:
Power consumption:
Electrical supply:
Input side
Output side
8

Order list

Name and description
Dräger X-zone Switch Off
Dräger X-zone Switch On
Dräger X-zone Switch Off/On
317 x 325 x 730 mm
(W x D x H)
approx. 22 kg
-20 °C to +50 °C
IP 54
max. 12 W
400 V, 3 phase + N, 50 Hz
Ex CEE 400 V,
3 phase plug
ExCEE 400 V,
3 phase socket
317 x 325 x 730 mm
(W x D x H)
approx. 22 kg
-20 °C to +50 °C
IP 54
max. 12 W
400 V, 3 phase + N, 50 Hz
Ex CEE 400 V,
3 phase plug
Ex CEE 400 V,
3 phase socket
Order no.
83 22 260
83 22 270
Technical data
11
