GB
adapter (48). Tighten screw (47) again when you are
satisfied with the adjustment.
9.2 Use as a laser level unit (Fig. 18-21)
Remove the screw (47). The laser (45) can now be
taken off the adapter (48) and used as an external
laser level unit. The laser (45) is equipped with two
spirit levels (49) and can therefore be adjusted both
horizontally and vertically. The base plate (50) of the
laser is magnetic, enabling it to be secured on
suitable surfaces.
See Figures 20 and 21 for two examples of use.
9.3 Replacing the battery
Unscrew the 4 screws (51) and remove the base
plate (50). Take out the old batteries and replace
with new ones. Then screw the base plate (50) back
on.
Dismantle the laser before you clean the machine
with water.

10. Maintenance

Clean off all dust and soiling from the machine at
regular intervals, preferably with a cloth or a
brush.
Lubricate all moving parts at regular intervals.
Do not use any aggressive cleaning agents to
clean plastic parts.
Clean off any soiling on the trough (3) and
cooling agent pump (13) at regular intervals,
otherwise the diamond cutting wheel (2) may not
be cooled as required. To empty the trough,
remove the rubber stopper (36) and drain the
water into a suitable vessel (Fig. 15).

11. Ordering replacement parts

Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
