Parameter Setting Menu
OUT 3400(X)-071 Module
Output current I3
• Process variable
• Characteristic
• Output
• Output filter
Behavior during messages
• HOLD
• 22-mA message
Output current I4
• Process variable
• Characteristic
• Output
• Output filter
Behavior during messages
• HOLD
• 22-mA message
Limit contacts K5 ... K8
(all separately definable)
• Process variable
• Limit value
• Hysteresis
• Effective direction
• Contact type
• ON delay
• OFF delay
OUT 3400(X)-071
Depending on modules installed: Off, S/cm, °C, % by wt, g/kg,
Ωcm, pH, ORP, rH, etc.
Linear, trilinear, function, table
0 ... 20 mA, 4 ... 20 mA
0000 s, xxxx s
Current meas., Last usable value, Fixed 22mA
On / Off
Depending on modules installed: Off, S/cm, °C, % by wt, g/kg,
Ωcm, pH, ORP, rH, etc.
Linear, trilinear, function, table
0 ... 20 mA, 4 ... 20 mA
0000 s (entry xxxx s)
Current meas., Last usable value, Fixed 22mA
On / Off
Depending on modules installed: Off, S/cm, °C, % by wt, g/kg,
Ωcm, pH, ORP, rH, etc.
Entry
Entry
Min ,Max
N/O, N/C
0000 s (entry xxxx s)
0000 s (entry xxxx s)
