In accordance with IKA warranty conditions, the warranty
®
period is 24 months. For claims under the warranty please
contact your local dealer. You may also send the machine
direct to our factory, enclosing the delivery invoice and giv-
ing reasons for the claim. You will be liable for freight costs.
Pump performance curve measured with water
0,6
0,4
0,2
P [bar]
0,0
-0,2
-0,4
0
Fig. 18

Warranty

Pump performance curve

5 10
Q [l/min]
The warranty does not cover worn out parts, nor does
it apply to faults resulting from improper use, insufficient
care or maintenance not carried out in accordance with
the instructions in this operating manual.
15 20
4000 rpm
3000 rpm
1000 rpm
