Fig. 5.1
In order to change the injector (1), unscrew the fittings (2). Ensure the connections are her-
metically tightened upon changing.
5.2

In-service testing

The switching of cycles and monometer readings should be monitored every day.
Once per month, the injector (8) and silencer (5), as given in figure 3.5, should be disas-
sembled for inspection and cleaned of oil and dust if necessary.
5.3

Checking drive belt

Under standard conditions, for which the adsorption compressed air dryer is designed, the
adsorbent has a minimum service life of three years before it loses its moisture-adsorbing
properties.
The following steps should be carried out to change the dryer:
COMPRAG Heatless adsorption compressed air dryers
2
If these procedures aren't carried out, then the dryer may fail to
operate properly, which will lead to noticeable deterioration in
the quality of air at the outlet of the dryer.
Deterioration of adsorbent can lead to reduced performance of
the air dryer. If you are unable to monitor the quality of dried air,
then you should change the adsorbent every 3 years.
1
2
ADX Series
17
