the temperature falls to room temperature, in order to prevent burns or injury.
12. Naked flames must not be used as a light source for inspecting and checking equipment.
13. Never use caustic solvents, which may damage materials of the pneumatic system
14. After performing installation or other work, ensure that no instruments, rags or spare
parts have been left inside the equipment.
15. Pay particular attention to the safety-relief valves. Thoroughly inspect them and remove
any dust and dirt. They must not be allowed to suffer any loss in function under any circum-
stances. Remember that your safety depends on their functionality!
16. Before beginning work in normal mode after maintenance or repair work, check that the
working pressure, temperature and other characteristics are correctly set. Ensure that all
control devices are installed and functioning properly.
17. When replacing filters, separators etc., wipe away dust, dirt and oil residue from the area
where they are installed with a dry cloth.
18. Protect the motor, air filter, electrical components and control components etc. from com-
ing into contact with condensate. For instance, blow down with dry air.
19. Use protective gloves during installation and repair work in order to avoid burns and injury
(for instance, during oil change).
2.

Design and mechanism

2.1

Technical information

The product features of COMPRAG heatless adsorption compressed air dryers are given
below:
Model
Product code
Air consumption*, (m3/min)
Maximum working pressure, bar
Max. temperature of compressed
air at inlet to air dryer, °C
Min./max. ambient temperature,
°C
Dew point temperature, С
8
Non-compliance with these instructions, use of non-original parts and
absence of a warranty service coupon may invalidate the warranty.
ADX20
14400050
2.0
ADX30 ADX40
14400051 14400052
3.0 4.0
10
+55
+5/+45
-40
ADX50 ADX70
14400053 14400054
5.0 7.0
