Start up

3.1 Lifting

Visually inspect for damages to packaging, and if there are no damages, then place the unit
near the site chosen for installation and unpack the unit. Equipment must only be moved
using the appropriate handling devices or hoisters.
Equipment must not be manually lifted or moved. Even when packaged, store the
equipment in a place shielded from weather conditions.
Handle with care. Heavy impacts (bumps and falls) may cause irreparable damage.

3.2 Dimensions

The appearance of the air dryer is shown in figure 3.2
D
Fig. 3.2 Air dryer dimensions.
12
The presence of dents, chips and other damages may invalidate
the warranty.
H
ADX125
ADX160
ADX200
ADX250
W
.
Model
Height H,
mm
ADX20 1220
ADX30 1500
ADX40 1850
ADX50 2130
ADX70 1820
ADX90 2120
2335
2325
2330
2645
Air dryer
Width W, Depth D,
(mm) (mm)
600
800
800
955
1275
1335
1000
1435
Version 1.0
Weight,
kg
90
111
175
205
250
310
496
565
720
805
