3.4 Drive-output interface

The drive motors can be supplied with different output shafts. The
shaft-hub connection is to be created properly and without using force.
If a pinion is mounted on the output shaft of a motor without a gearbox,
the rear shaft end of the motor has to be supported.
WARNING!
If too much force is applied when creating the mechanical
connection the motor may be damaged or destroyed!

3.5 Electrical connection

WARNING! Danger of electric shock!
Work on electrical components can only be performed by spe-
cialist electricians under observance of the safety guidelines.
Before starting work, switch off the electrical power supply
and prevent it being switched back on. All lines are to be
fused properly. Observe the circuit diagram of the motor!
It is mandatory to observe the following sequence:
1. Connect the motor in accordance with the terminal connection /
circuit diagram (Point 5).
2. Check all line connections.
3. Ensure that a correct protective earth connection is provided.
