3 Assembly

3.1 Safety guidelines

WARNING!
The device is to be installed in a machine or system, so that:
•
•
•
If there is a danger that the motor may be touched, then it has
to be covered. When doing so the heat dissipation must not be
affected.

3.2 Description

Mounting screws are not supplied. Here the specifications of the opera-
tor have to be observed.
Legend:
1 Supporting area with
attachment holes
2 Flange
3 Terminal box (optional)
4 Connecting lead wires
5 Motor shaft
There is no hazard to people, animals and property due
to electric shock and a protective earth connection is
guaranteed!
There is no mechanical hazard to people, animals and
property.
There is no thermal hazard to people, animals and
property.
Figure 1: Example motor outline drawing
