Operation; Connections And Controls - Lightmaxx VECTOR Spot 200 Bedienungsanleitung

Operating mode Auto or Sound:
The device contains automatic programs that run according to fixed patterns (Auto) or are recalled
via the built-in microphone to match the music (Sound). The selection of the respective mode is
made via the menu directly on the device.

Operation:

Start:
Connect the device to the mains and wait a few seconds until it is ready for operation.

Connections and controls:

1
Lense
2
Display
3
Menu keys
4 Carrying handle
5 DMX Input (3 pin)
26
6
DMX Output (3 pin)
7
ON/OFF switch
8
Power Input (PowerCon compatible)
9 Power Output (PowerCon compatible)
10 Fuse
